KONG Ovalone DNA Twist Lock ANSI Carbon Steel Carabiner | Lunar White
The KONG Ovalone DNA Twist Lock ANSI is a high-strength carbon steel carabiner with a distinctive helical body that allows a 90-degree orientation change for connected equipment. This specialized geometry helps align descenders, rope clamps, fall arresters, and other compatible devices in professional rope access, technical rescue, and fall protection systems.
The connector features a two-action Twist Lock automatic locking sleeve that requires the user to rotate the sleeve and open the gate. Its twisted oval body lets connected equipment sit perpendicular to the attachment point, improving orientation in applications requiring an offset connection.
Manufactured from carbon steel, the Ovalone DNA provides a 40 kN major-axis strength rating and a 15 kN minor-axis strength rating.
The Lunar White finish uses a zinc-nickel treatment that provides twice the corrosion resistance of conventional black zinc plating, according to KONG's salt-spray testing under UNI EN ISO 9227. The treatment also provides a uniform finish and improved scratch resistance.
Manufactured in Italy, the Ovalone DNA Twist Lock ANSI combines specialized connector geometry with high-strength construction for demanding professional applications.
Features and Benefits
Helical-shaped carbon steel body provides a 90-degree orientation change for connected equipment.
Helps align compatible descenders, rope clamps, and fall arresters.
Two-action Twist Lock automatic locking sleeve.
High-strength construction with a 40 kN major-axis rating.
15 kN minor-axis strength rating.
Oval-shaped body with circular cross-section.
Keylock nose design helps reduce snagging during connection and removal.
17 mm gate opening.
Lunar White zinc-nickel finish provides enhanced corrosion and scratch resistance.
ANSI Z359.12 and EN 362 Type M compliant.
Manufactured in Italy.
Kong USA
Technical Specifications
Specification | Details |
|---|---|
Manufacturer | KONG |
Product | Ovalone DNA Twist Lock ANSI |
Product Type | Helical Automatic-Locking Steel Carabiner |
Material | Carbon Steel |
Shape | Twisted Oval / Helical |
Locking Mechanism | Two-Action Twist Lock |
Nose Design | Keylock |
Major-Axis Strength | 40 kN |
Minor-Axis Strength | 15 kN |
Open-Gate Strength | Not specified |
Weight | 235 g (8.29 oz) |
Length | 108 mm |
Width | 65 mm |
Gate Opening | 17 mm |
Finish | Lunar White, Zinc-Nickel |
Country of Manufacture | Italy |
Certifications and Standards
Standard | Description |
|---|---|
ANSI Z359.12 | American National Standard for connecting components used in personal fall arrest systems |
EN 362 Type M | European standard for multipurpose connectors used in personal protective equipment |
Available Configuration
Configuration | Finish | Manufacturer SKU | Major-Axis Strength |
|---|---|---|---|
Ovalone DNA Twist Lock ANSI | Lunar White | 414LI0999KK | 40 kN |
